Technical data

1. Dimensions and Weight

  • Length: 7.9 m
  • Wing Span: 12.5 m
  • Height: 2.5 m
  • Maximum Take-Off Weight (MTOW): 6,500 kg
  • Payload Capacity: 1,200 kg

2. Performance

  • Propulsion: Turbofan
  • Service Ceiling: 40,000 ft
  • Endurance: 10 hours @ 30,000 ft
  • Maximum Speed: 425 knots / 0.7 Mach @ 30,000 ft
  • Cruise Speed: 250 knots / 0.42 Mach @ 30,000 ft

3. Features

  • Common Avionics Architecture and Ground Segment with ANKA and AKSUNGUR
  • Low Radar Observability
  • High Subsonic Speed
  • High Payload Capacity
  • 2 Internal and 5 External Payload Stations
  • Internal / External Fuel Tanks
  • Manned-Unmanned Teaming (MUM-T)
  • Swarm Technologies Combined with AI

4. Payloads

  • ISR: EO/IR Camera, SAR/GMTI-ISAR Radar
  • Electronic Warfare: COMINT, ELINT, ESM (Electronic Support Measure), EA (Electronic Attack), ComJam (Communication Jamming)
  • Weapons: Precision Guided Bombs, Laser Guided Rockets, Anti-Tank Missiles
  • Operation Support: SATCOM, Radio Relay, Air Launched Drone, AIS (Automatic Identification System), PLS (Personnel Locator System), ELT (Emergency Locator Beacon), RVT (Remote Video Terminal), TCAS (Traffic Collision Avoidance System)
