Technical data

1. Dimensions and Weight

• Wing Span: 10.91 m
• Length: 11.17 m
• Height: 3.80 m
• Wing Area: 16.30 m²
• Fuselage Length: 10.8 m
• Fuselage Height: 2.16 m
• Fuselage Width: 1.01 m
• Maximum Take-Off Weight (MTOW): 9,980 lb / 4,530 kg
• Endurance: 4.3 hours

2. Performance

• Fuel Capacity (Internal / External): 1,160 lb (526 kg) / 650 lb (300 kg)
• Maximum Cruise Speed: 278 knots / 515 km/h
• Maximum Rate of Climb: 3,297 fpm / 16.75 m/s
• Service Ceiling: 30,000 ft / 9,144 m
• Maximum Range: 750 NM / 1,390 km
• Positive / Negative G Limit: +5 / -2.4 G

3. Weapon Systems

• Laser Guided Missile (Anti-tank, Anti-personnel)
• 250 lb / 500 lb Laser & INS/GPS Guided Bombs
• 2.75" Laser Guided Rockets
• External Fuel Tanks
• 12.7 mm Gun Pod
• Laser Guided Micro Munitions
• Training Bombs

4. Roles

• Intelligence, Surveillance and Reconnaissance
• Forward Air Controller (Airborne)
• (Combat) Search and Rescue
• Patrol and Border Security
• Counter-Terrorism Operations
• Close Air Support
• SAT (Surface Attack)

5. Features

• Satellite Phone
• Video Downlink
• Self Protection System
• Mission Planning Ground Station
