Technical data

1. Dimensions and Weight

• Length: 20.2 m
• Height: 3.8 m
• Main Rotor Diameter: 16.70 m
• Maximum Take-Off Weight (MTOW): ~12,000 kg
• Crew: 2
• Passenger Capacity: 19

2. Performance

• Max Speed: 175 KIAS
• Range: 280 nautical miles
• Endurance: ~2.75+ hours
• HIGE Ceiling: 12,850 ft @ MTOW
• HOGE Ceiling: 8,450 ft @ MTOW
• Rate of Climb: 3,220 fpm
• Service Ceiling: 20,000 ft

3. Features

• Hot & High Mission Capability
• State-of-the-Art Avionics Systems
• Large Cabin Area
• Day and Night Mission Capability
• Automatic Blade Folding and Tail Folding (Marine Configuration)
• Cargo Hook
• Rescue Hoist
• Search and Weather Radar
• Rotor Ice Protection System

4. Power Plant

• Turboshaft Engines

5. Roles

• Transportation
• Cargo
• Off-Shore
• Search and Rescue
• Firefighting
• Air Ambulance
• VIP
