Technical data

1. Dimensions / Weight

• Length: 19.76 m
• Main Rotor Diameter: 16.36 m
• Tail Rotor Diameter: 3.35 m
• Maximum Take-Off Weight (MTOW): 9,980 kg / 22,000 lbs
• Maximum Gross Weight with External Load: 10,659 kg / 23,500 lbs
• Maximum External Load: 4,082 kg / 9,000 lbs
• Crew: 2
• Passenger Capacity: 12
• Cabin Width: 2.14 m / 7.0 ft
• Cabin Height: 1.37 m / 4.5 ft
• Cabin Area: 8.18 m² / 88 ft²
• Cabin Volume: 11.22 m³ / 396 ft³

2. Performance

• Maximum Cruise Speed: 296 km/h / 160 kt (Standard day, sea level)
• HIGE (Hover In Ground Effect): 4,572 m / 15,000 ft (at 18,000 lbs GW)
• HOGE (Hover Out of Ground Effect): 3,353 m / 11,000 ft (at 18,000 lbs GW)
• Service Ceiling: 6,096 m / 20,000 ft (at 18,000 lbs GW)

3. Roles

• Personnel Transportation
• External Lift
• Cargo
• Medical Evacuation
• Firefighting
• Search and Rescue
• Maritime Patrol and SAR
